Greenlee 6906 UT10 Package with Mobile Versi Boom
Greenlee 6906 UT10 Package with Mobile Versi Boom
Greenlee 6906 UT10 Package with Mobile Versi Boom
Greenlee 6906 UT10 Package with Mobile Versi Boom
Greenlee 6906 UT10 Package with Mobile Versi Boom

Greenlee 6906 UT10 Package with Mobile Versi Boom

Regular price
/

$13,150.99 USD & FREE Shipping.
  • 2 Speed Ultra Tugger (UT10-2S) is a one-stop-shop: The only 2 speed puller on the market that can shift from high speed/low load pulling to low speed/high load pulling with a simple double tap motion on the foot pedal control switch
  • Use for cable pulls requiring high as well as low pulling loads
  • The no-load high speed is 16 FT/MINT and is best suited for loads up to 4000 LB where the speed will be 12 FT/MINT
  • The no-load low speed is 9 FT/MINT and can be used on loads up to 8000 LB where the speed will be 6 FT/MINT, or a momentary peak capacity of 10000LB
  • 2-Speed motor that delivers the fastest pulling time for all pulling needs over the widest (10000 LB) range
Overview

The Greenlee UT10 Ultra Tugger® Cable Puller is intended to be used to pull cable through conduit and in tray. The UT10 will develop 44.5 kN (10,000 lb) of pulling force. Refer to a Greenlee catalog for sheaves, pulling rope, and other cable pulling accessories to create an entire cable pulling system.

No single manual can provide instructions for every possible cable pulling application; this manual contains general information necessary to accomplish cable pulls of many different setups.

Greenlee 6906 UT10 Package with Mobile Versi Boom

Specifications
General Information
Brand
Greenlee
Part Number
6906
Product Type
Puller Assembly
Application
Electrical Cable pull
Packaging
Retail
Country of Origin
United States
UPC
783310003595
California Residents
Proposition 65 Warning
Return Policy
NCNR - Non-Cancellable / Non-Returnable
Physical Characteristics
Weight
212.28 kg
468.00 lb
Details
Features
2 Speed Ultra Tugger (UT10-2S) is a one-stop-shop: The only 2 speed puller on the market that can shift from high speed/low load pulling to low speed/high load pulling with a simple double tap motion on the foot pedal control switch
Use for cable pulls requiring high as well as low pulling loads
The no-load high speed is 16 FT/MINT and is best suited for loads up to 4000 LB where the speed will be 12 FT/MINT
The no-load low speed is 9 FT/MINT and can be used on loads up to 8000 LB where the speed will be 6 FT/MINT, or a momentary peak capacity of 10000LB
2-Speed motor that delivers the fastest pulling time for all pulling needs over the widest (10000 LB) range
Strong, rugged motor designed specifically for both big and small cable pulling applications up to 10000 LB
Easy control features for increased productivity: On-board force gauge provides visual communication of pulling force and speed changes
Quick speed change from high speed to low-speed by simply double tapping foot pedal
Removable foot pedal for convenience
Sets up in less than 2 minutes and can be used in every pulling situation
This combination of speed and versatility can increase your productivity, equaling more pulls in a day and delivering greater benefit to your bottom line

Load: 0 - 6500.000 LB (0 - 28.900 KN) Continuous Operation, 6500.000 - 8000.000 LB (28.900 - 35.600 KN) 15 Minutes ON/15 Minutes OFF, 8000.000 - 10000.000 LB (35.600 - 44.500 KN) Momentary
Cable Type: Electrical Cable
Mounting: Mobile versi Boom
Prime Mover Specification: Required Rope: 7/8" diameter, double-braided, polyester composite Average Breaking Strength: 143 kN (32,000 lb) minimum
Capacity: The no-load low speed is 9 FT/MINT and can be used on loads up to 8000 LB where the speed will be 6 FT/MINT, or a momentary peak capacity of 10000LB
Amperage Rating: 20 Amp
Voltage
115 Volts
Why would you use this tool for ?
About manufacturer
Greenlee

Founded in 1862, Greenlee Tools got its start as a toolmaker when two brothers needed to manufacture their invention (a special drill surrounded by chisels). With the success of this effort, the Greenlee brothers quickly took on making other woodworking tools and other machinery including a machine that laid track for the railroad. In the mid-80s and beyond, Greenlee added on other toolmakers and diversified the kinds of tools they make and now Greenlee manufactures tools used by tradesmen in all vocations from communications to hydraulic pumps, plumbing, telecom, test equipment and many more. Greenlee is widely recognized as an industry leader for quality hand and industrial tools.
